Built-in box Stop air, diameter 67mm, depth 40mm spécial

STOPAIR DEBFLEXWATERPROOF SWITCHGEAR BOX

This DEBFLEX brand Stopair equipment box is a mounting bracket used in the installation of electrical mechanisms. It is used to fix devices such as sockets, chargers, switches and push buttons. This bracket is specially designed for drywall with a depth of 40 mm. This box is able to accommodate a single station mechanism with a diameter of 67 mm. It is capable of handling 16A of electrical current, with a nominal voltage of 240V. The bracket is protected against air and water intrusion by its high IP55 sealing level.

Product advantages :

• Cable entries that can be knocked out
• Quick and easy installation

General characteristics:

• Brand : DEBFLEX
• Range : Stopair
• Reference : DEB718382
• Dimensions: 74 x 74 x 40 mm
• Diameter: 67 mm
• Weight : 245 g

Product features:

• Ratedcurrent: 16 A
• Rated voltage: 240 V
• Rated power: 3600 W
• Number of positions: 1
• Waterproofing level: IP55
• Colour: grey/blue
• Material: PP / SBS / Steel / PA 66
• Operating temperature : -5°C to +50°C
• Storage temperature: 25°C
